Recently I was asked to take a look at a IC-910h VHF/UHF all-mode transceiver which had developed an issue where the bias kept being enabled. Even on transmit and when the preamp wasn’t enabled. It luckily didn’t cause any havoc as the operator’s antenna wasn’t DC shorted at the time..
If you look at one of my previous posts – you’ll know how a basic bias circuit works (check it out here – SEA remote ATU bias & mods).
The problem here, was that there was no way of turning it off and on. Nothing seemed to be burnt out or shorted on first sight. So what does this look like on the schematic?…
